Woven geotextile fabric is a high-strength geosynthetic material widely used in road construction, ground stabilization, embankment reinforcement, and heavy-load engineering projects.As a professional geotextile manufacturer and supplier with over 10 years of experience,Planetliner supplies different types of woven geotextiles including high-strength woven geotextile and standard woven geotextile fabrics manufactured from polypropylene and polyester materials.
Our woven geotextile products are designed to provide excellent tensile strength, low elongation, and long-term durability in demanding construction environments.
1.What Is Woven Geotextile Fabric
Woven geotextile is produced by weaving synthetic fibers or tapes to form a stable and strong fabric structure.
Compared with nonwoven geotextiles, woven fabrics provide:
- Higher tensile strength
- Lower elongation
- Better load distribution
- Excellent reinforcement performance
Because of these properties, woven geotextiles are commonly used in infrastructure and heavy-duty engineering projects.
2.Types of Woven Geotextile We Supply
2.1High Strength Woven Geotextile
High-strength woven geotextile is designed for projects requiring high load bearing capacity and reinforcement.
Key Features
- High tensile strength
- Excellent dimensional stability
- Suitable for heavy traffic loads
- Long service life
Typical Applications
- Highway construction
- Railway subgrade stabilization
- Industrial yard reinforcement
- Embankment strengthening
This type of woven geotextile is commonly used where structural stability and soil reinforcement are critical.
Meanwhile, there are Polyester Woven geotextile and Polypropylene woven geotextile.
2.2Standard Woven Geotextile Fabric
Standard woven geotextile provides reliable separation and reinforcement at a more economical cost.
Key Features
- Good tensile strength
- Cost-effective solution
- Easy installation
Typical Applications
- Road base separation
- Temporary construction roads
- Agricultural ground stabilization
3.Materials of Woven Geotextile
Polypropylene Woven Geotextile:Polypropylene woven geotextile is the most commonly used material due to its durability and chemical resistance.
Advantages
- Excellent chemical and biological resistance.
- Good UV resistance with stabilized grades.
- Cost-effective solution for large-scale projects.
Applications
- Road construction
- Subgrade reinforcement
- Drainage projects
Polyester Woven Geotextile:Polyester woven geotextile offers higher temperature resistance and dimensional stability.
Advantages
- High tensile strength
- Low creep
- Good performance in high-temperature environments
Applications
- Heavy engineering projects
- Industrial ground stabilization
4.Major Applications of Woven Geotextile
Woven geotextile fabric is widely used in various civil engineering projects.
- Road Construction and Subgrade Stabilization
- Prevents mixing of soil layers and improves load distribution.
- Ground Reinforcement
- Enhances bearing capacity and reduces settlement.
- Embankment and Slope Protection
- Improves structural stability and prevents erosion.
- Construction Platforms
- Provides stable working surfaces for heavy equipment.
5.Woven Geotextile Specifications
5.1Polyester PET High strength woven geo textile specifications:
Tensile strength:80/50,100/50,200/50,400/50,600/50,800/50,1000/50,1200/50,2000/50. 80/80,100/100,200/200,400/400,600/600kN/m.
Width:3.5m 4m 5.2m
Length:50m 100m 200m or 300m
5.2 Polypropylene PP High strength woven geo textile specifications:
Tensile strength:40/40,50/50,60/60, 80/80,120/120,175/175,200/200,300/300kN/m.
Width:4.6m 5.2m
Length:100m 200m or 300m
5.3 Polypropylene PP Standard woven geo textile specifications:
Tensile strength:20/20,40/40,80/80,100/100,140/140,160/160,180/180 kN/m
Width:1-6m
Length:100m 200m or 300m
6.How to Select the Right Woven Geotextile
Choosing the correct woven geotextile depends on:
- Soil conditions
- Load requirements
- Project lifespan
- Installation environment
Our engineering team can recommend suitable specifications based on your project data.
7.Woven Geotextile Installation Overview
Typical installation steps include:
- Subgrade preparation
- Geotextile placement
- Overlap and anchoring
- Cover layer installation
Proper installation ensures long-term performance and durability.
8.Woven Geotextile Price Factors
The cost of woven geotextile depends on:
- Tensile strength
- Material type
- Roll width
- Project quantity
- Transportation distance
- Bulk orders usually receive more competitive pricing.
Request a quotation based on your project specifications.
9.Frequently Asked Questions
9.1What is the difference between woven and nonwoven geotextile?
Woven geotextile provides higher tensile strength and reinforcement, while nonwoven geotextile is mainly used for filtration and drainage.
9.2What strength of woven geotextile should I choose?
This depends on soil conditions and load requirements. Engineers typically select tensile strength based on design standards.
9.3Can woven geotextile be used with geomembrane?
Yes. Woven geotextile is often used as reinforcement or separation layers in geomembrane systems.
Request Woven Geotextile Quotation
If you are planning a road, stabilization, or reinforcement project, our team can help you select the correct woven geotextile solution.
Contact us today for project consultation.
