What is HDPE liner?
HDPE liner is also named hdpe geomembrane,a kind of pond liner.It is made of high-density polyethylene resin, with carbon black material.The hdpe liner is waterproof,impermeable, UV resistant,chemical resistant, puncture resistant,hdpe liner has high tensile strength, is widely used for fish pond, water dam, water treatment, oil gas, landfill,mining, root barrier and so on,hdpe liner is becoming more and more popular containment structure.
HDPE liner technical data
| Item | Property | Test method | Thickness | Thickness | Thickness | Thickness | Thickness |
|---|---|---|---|---|---|---|---|
| 0.75mm | 1mm | 1.25mm | 1.5mm | 2mm | |||
| 1 | Density g/cm3 | ASTM D1505/D792 | 0.94 | 0.94 | 0.94 | 0.94 | 0.94 |
| 2 | Tensile properties | ASTM D6693 | |||||
| Yield Strength N/mm | 11 | 15 | 18 | 22 | 29 | ||
| Break Strength N/mm | 20 | 27 | 33 | 40 | 53 | ||
| Yield Elongation % | 12 | 12 | 12 | 12 | 12 | ||
| Break Elongation % | 700 | 700 | 700 | 700 | 700 | ||
| 3 | Tear Resistance N | D1004 | 93 | 125 | 156 | 187 | 249 |
| 4 | Puncture Resistance N | D4833 | Column 4 Value 9 | Column 5 Value 9 | Column 6 Value 9 | Column 7 Value 9 | Column 8 Value 9 |
| 5 | Carbon Black Content % | D4218 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 |
| 6 | Stress Crack Resistance N | D5397 | 500 | 500 | 500 | 500 | 500 |
